Solar Hybrid Inverter – EM-T Series (Dual AC Output)

Model: EM-T

Solar Hybrid Inverter – EM-T Series is designed for superior performance with guaranteed price, quality, and service.

As a leading manufacturer, we export globally, earning the trust of distributors and dealers worldwide. Our inverters ensure high efficiency and reliability for various energy solutions.

EMT6200-48L Solar Hybrid Inverter – 6.2kW, 48V, Dual AC Output
Advanced Hybrid Inverter for Off-Grid and Grid-Assist Solar Applications

The EMT6200-48L 6.2kW Solar Hybrid Inverter is a next-generation, intelligent power management solution designed for hybrid solar systems. Built for high efficiency and flexibility, this inverter seamlessly integrates solar, grid, and battery inputs, with advanced features such as dual AC output, dual MPPT, and parallel scalability, making it ideal for complex residential or small commercial energy storage systems.

Whether for backup, off-grid, or hybrid installations, the EMT6200-48L empowers energy independence with reliable, high-performance operation.

-Dual AC output

-Built-in 2 MPPT

-Parallel max up to 6 units

-Lithium battery activation function by PV or Utility

-Compatible work with LiFePO4 battery viaRS485

-Pure Sine Wave

-Power factor 1.0

-PV Input 500Vdc Max

-Built-in MPPT140A/160A

-Capable to work without battery

-Detachable dust cover for harsh environment

-Wifi remote monitoring optional

-Support multiple output priority: SUB, SBU, SUF

-EQ function to optimize battery performance and extend lifecycle

Key Features:

  • Rated Power: 6.2kW pure sine wave output for stable and efficient power supply

  • Battery Voltage: 48VDC system compatible with both lithium and lead-acid batteries

  • Dual MPPT Technology: Maximizes solar energy harvest with up to 6000W PV input

  • Dual AC Output: Separates critical and non-critical loads for smart energy distribution

  • Parallel Operation: Supports up to 6 units in parallel for system expansion

  • Flexible Operation Modes: Off-grid, hybrid, and grid-assist configurations

  • Advanced Monitoring: Built-in LCD display, optional WiFi app, and RS485/BMS communications

  • Comprehensive Protection: Safeguards against overload, short circuit, overcharge, and reverse polarity

Ideal For:

  • Residential hybrid solar energy storage systems

  • Light commercial backup power and microgrids

  • Remote solar installations with grid support

  • Solar-powered critical infrastructure in developing regions

  • B2B solar distributors, OEM/ODM solution providers

Designed for Global Renewable Energy Projects

With smart energy flow control, flexible system configuration, and rugged performance, the EMT6200-48L is the trusted choice for professional installers and solar businesses worldwide.

OEM & ODM customization available for international partners. Contact us today to bring high-performance hybrid inverters to your market.

Model EM6200T-48L
Phase 1-Phase In/1-Phase Out
Max. PV Input Power 6500W
Max. Main Output Power 6200VA/6200W
Max. Second Output Power 6200VA/6200W
Max. Total Output Power 6200VA/6200W
Parallel Capability NO
Lithium Battery Activation YES (By PV or Utility)
Lithium Battery Commnication YES (RS485)
AC Input
Nominal Voltage 230VAC
Acceptable Voltage Range 170-280VAC (For Personal Computer); 90-280VAC (For Home Appliances)
Frequency 50/60 Hz (Auto Sensing)
Output
Nominal Voltage 220/230VAC ±5%
Surge Power 12400VA
Frequency 50/60Hz
Waveform Pure Sine Wave
Transfer Time 10ms (For Personal Computer); 20ms (For Home Appliances)
Peak Efficiency (PV to INV) 94%
Overload Protection 5s@>=140% Load; 10s@110%~140% Load
Crest Factor 3:01
Admissible Power Factor 0.6~1 (Inductive or Capactive)
Battery
Battery Voltage 48VDC
Floating Charge Voltage 54VDC
OverCharge Protection 63VDC
Charge Method CC / CV
Solar Charger & AC Charger
 Solar Charger Type MPPT
Max. PV Array Power 6500W
Max. PV Array Open Circuit Voltage 500VDC
PV Array MPPT Voltage Range 60VDC ~ 500VDC
Max. Solar Input Current 1/27A
Max. Solar Charge Current 120A
Max. AC Charge Current 80A
Max. Charge Current 120A
Physical
Dimensions 438*312*122 mm
Package Dimensions 540*390*210 mm
Net Weight 11 KGS
Communication Interface RS232 + RS485
Environment
Operating Temperature Range -10 ~ 50ºC
Storage Temperature -15 ~ 50ºC
Humidity 5% to 95% Relative Humidity (Non-Condensing)
